USB3.0 HDMI 4K High Definition Video Capture Card HDMI to USB Video Capture Dongle for Winodws Live Streaming
100% brand new and high quality
HDMI to USB3.0 video capture card is easy to carry, has excellent performance, outstanding compatibility, simple installation and many other functions.
It can capture an HDMI 4K30Hz input signal.
USB3.0, speed 300-350MB / s, compatible with USB 2.0.
Can capture a single channel high-definition HDMI video signal.
Can automatically detect the input video format, and automatically adjust the output size and frame rate.
The input can support up to 4K30, and the output supports 1080P 60HZ.
Compatible with UVC video capture and YUV 422 video output.
Compatible with for Windows, for Linux, for MacOS X and USB 3.0 interfaces, compatible with many USB 3.0 chipsets (for In-tel), compatible with PCIe Gen1.1 x1 expansion through USB 3.0 interface.
HDMI video capture complies with UVC and UAC standards, no need to install drivers and settings, easy to use.
Attention: it can only support for i5 desktop computer, for i7 and above CPU notebooks.
Item Type: HDMI to USB3.0 Video Capture
Material: aluminum shell
Color: Grey, Blue(Optional)
Host interface: USB3.0, 300-350MB/s; USB2.0, 40MB/s
Input interface: HDMI interface
HDMI input format: 4K30HZ 480i, 480p, 576i, 576p, 720p50, 720p60, 1080i50, 1080i60, 1080P24/25/30/60
Supported resolutions for output:
640 × 480/720 × 480/720 × 576/768 × 576/800 × 600/1024 × 768/1280 × 720/1280 × 800/1280 × 960/1280 × 1024 / 1368×768 / 1440/1600 × 1200/1680 × 1050/1920 × 1080/1920 × 1200/640 × 360 / 856×480 / 960 × 540 / 1024×576
Frame rate: 25 / 29.97 / 30/50 / 59.94 / 60 fps
Power consumption: less than and equal to 2.5W
Operating temperature: 0-50 degrees Celsius
Storage temperature: -20-70 degrees Celsius
Storage humidity: 5%-90%
Quantity: 1 Pc
Connection and operation:
1.Connect Blu-ray player, Play Station, audio / video receiver, satellite receiver and other signal sources with HDMI output interface and HDMI cable to the HDMI input of the device.
2.Insert the USB3.0 cable head into the USB3.0 interface, and plug the other end of the cable into the USB3.0 interface of the computer.
3.HDMI to USB3.0 video capture Dongle is based on UVC (USB video class), UAC (USB audio class).
Please allow 0-1cm error due to manual measurement. pls make sure you do not mind before you bid.
Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you!
1 x HDMI to USB3.0 Video Capture
1 x USB power cable
1 x USB3.0 connection cable
1 x HDMI cable
1 x User Manual
